Bus LED Advertising Screen

Wide range of the bus led display power:
Wide voltage range from 12V to 24V to adapt the buses;
Waterproof bus led screen:
With front plexiglas protection and outdoor SMD lamp, ensure the sign IP65;
Wide view angle led lamp:
Large view angle 140/140 degree and ultra brightness SMD lamp, picture is still vivid under the sunshine;
Slim design bus led sign:
Aluminum alloy material with thin and light weight, total thickness about 100mm;
Multi-control method for advertising led sign
With 3G, wifi or group control of the signs, GPS locking the place to place certain advertising.

详情介绍

Specifications

Bus advertising LED SCREEN	TBS-2.5	TBS-3	TBS-4	TBS-5	TBS-6	TBS-8	TBS-10	TBS-12.5
Pixel pitch(mm)	2.5	3	4	5	6	8	10	12.5
Pixel Density(dot/m2)	160000	111111	62500	40000	27777	15625	10000	6400
LED Type	SMD1415	SMD1921	SMD1921	SMD1921	SMD3535	SMD3535	SMD3535	SMD3535
Module Size(W x H x D)mm	160 x 160 320 x 160	192 x 192	256 x 128 320 x 160	160 x 160 320 x 160	192 x 192	256 x 128 320 x 160	320 x 160	200 x 200
Module resolution(W x H)	64 x 64 128 x 64	64 x64	64 x32	32 x 32 64 x 32	32 x 32	32 x16	32 x16	16 x16
Module Weight(Kg)	0.45	0.45	0.5	0.4/1	0.8	0.5	0.45	0.45
Power Consumption per Module(w)	30	30	35	42	30	25	45	25
Diver Mode(Scan)	1/16	1/16	1/16	1/16	1/16	1/16	1/16	1/16
Brightness(cd/m2)	≥5500	≥5500	≥6000	≥6000	≥6000	≥6000	≥6000	≥6000
Grey Scale(bits)	16	16	16	16	16	16	16	16
Refresh Rate(Hz)	≥1,920	≥1,920	≥1,920	≥1,920	≥1,920	≥1,920	≥1,920	≥1,920
Cabinet Size(W x H x D)mm	1650690mm / 1778626mm / 1970690mm / 2930690mm…can customize
Cabinet Weight(Kg/m2)	40	40	40	40	40	40	40	40
Max Power Consumption(W/m2)	800	800	900	900	900	900	900	900
Average Power Consumption(W/m2)	280	280	300	300	300	300	300	300
View Angle(H°/V°)	140/120	140/120	140/120	140/120	140/120	140/120	140/120	140/120
Mini View Distance(m)	2	3	4	5	6	8	10	12
Operating Use Temperature(℃)	-20℃~60℃
Storage Use Temperature(℃)	-20℃~60℃
Input Voltage(V)	9~36V
Input Power Frequency(Hz)	50Hz~60Hz
Failure Rate	＜1/100,1000
Signal Input Format	SDI, RGBHV,YUV,YC,Composite,HDMI,DVI,SD/HD-SDI etc.
Life Time(hrs)	100000
IP Level(front/rear)	IP65/IP56
	IP Level(front/rear)IP65/IP31
